General Function: hydraulic lifting and gravity lowering;
Actuation: electro-hydraulic;
System: automatic;
Control: easy-to-operate push buttons;
Electrical system: 12VDC or optional 24VDC;
Maximum consumption: max. 35A (24VDC) or 70A (12VDC).
Operating temperature: -25°C to 55°C;
Structure: lightweight and robust painted steel;
Coating: black and yellow electrostatic powder coating;
Weight: 170kg;
Auxiliary operating system: integrated manual pump.

Hydraulic pump with safety system that prevents the platform from closing with the user on it;
Automatically activated front guard;
Automatically activated rear guard that ensures greater user safety;
Manual pump for emergency situations;
Anti-vibration system to prevent possible noise;
Mechanical safety system that prevents the platform from opening unintentionally.

With the vehicle on a level surface, the brake engaged, and the engine running, it is necessary to keep the doors fully open before operating the lift.
Using the key, turn the switch and the system will turn on, activating the audible and visual signals. Using the manual control, release the locks using the “open” button until the platform is extended, and use the “down” option until the platform reaches floor level.
To return to the initial position or to board a passenger, the “up” function is used until the platform is at the level of the car. To close the platform, the “close” button on the control is held until the platform stops completely.
